Canopy surface cover

When the multiple leaf option is used the canopy cover of the plant has to be defined in order to estimate the partitioning of intercepted radiation between plants (see chapter “Soil evaporation, snow and radiation processes” for details on the radiation interception). The canopy surface cover is calculated as:

                                                   (3.11)

where p_cmax is a parameter that determines the maximum surface cover and p_ck is a parameter the governs the speed at which the maximum surface cover is reached. A_l is the leaf area index of the plant. Note that p_cmax can also be set to values greater than unity if the horizontal extension of the plant is larger than the soil. This is the case when a plant stands on a smaller area of soil than what it receives light from, e.g. a plant growing in a pot (described in detail below).

A horizontal positioning of plants in one dimension within the unit area of soil is defined in order to represent different degrees of shading between plants. The horizontal position of a plant j is defined by its canopy surface cover f_cc,j and its mid-position x_j (Figure 3.2). The mid-position of a plant x_j can be given as a fixed parameter or may be altered randomly each time step using the parameter x_x to initialise the randomiser (see switch SpatialDistribution random vs. parameters). Consequently it is possible to have two canopies covering the same area of soil and these plants will therefore compete for radiation, as described in “Soil evaporation, snow and radiation processes”.



Figure 3.2. Conceptual view of the spatial distribution of multiple canopies in one horizontal dimension, given as a function of the central position, x_j, and the fractional canopy cover, f_cc,j, of each canopy. p_cmax is the maximum horizontal canopy surface cover for each plant.

A canopy that reaches outside the unit area of soil can be considered in two different ways, as is illustrated in Figure 3.3. In a stand of identical neighbours, the part of the plant that is outside the unit area is reflected at the opposite side. The single “multiple” canopy (i.e. the plant in the pot case) is allowed to intercept radiation from a larger area than unity, in contrast to the stand of identical neighbours. The distinction between identical neighbours and single multiple canopies is defined by the switch SpatialDistribution.

Figure 3.3. Multiple canopies with horizontal extension outside the unit area of soil can be considered as a stand of identical neighbours (left panel) or as a single “multiple” canopy (right panel). The single “multiple” canopy is allowed to intercept radiation from a larger area than unity, in contrast to the stand of identical neighbours.

When using a single leaf the canopy surface cover is assumed to be equal to unity, i.e. completely covering the soil surface.
